Model No.: YLHCB-04/27-4310-22L Code:62601
Model No.: YLHCB-07/27-4310-22L Code:62602
Electrical Specifications | ||||||||||||
Frequency Range (MHz) | 400 ~ 2700 | |||||||||||
Attenuation P1 - P2(dB) | 3 ± 0.8 | |||||||||||
Attenuation P1 - P2(dB) | 3 ± 0.8 | |||||||||||
Isolation (dB) | > 20 | |||||||||||
VSWR | < 1.3 | |||||||||||
Insertion Loss (dB) | < 0.2 | |||||||||||
IM.3rd order (dBc) 2×43dBm | <-160 | |||||||||||
Impedance (Ω) | 50 | |||||||||||
Power Handing (W) | 150,Avg | |||||||||||
Mechanical Specifications | ||||||||||||
Input Connector | 2 × 4.3-10 Female | |||||||||||
Output connector | 2 × 4.3-10 Female | |||||||||||
Housing Materail | Aluminum Alloy | |||||||||||
Housing Color | Black | |||||||||||
Demensions (L×W×H)mm | 211 × 52 × 32 | |||||||||||
Weight (Kg) | 0.5 | |||||||||||
Operating Temprature (℃) | -40~+60 | |||||||||||
Application | Outdoor, IP65 |
Electrical Specifications | ||||||||||||
Frequency Range (MHz) | 700 ~ 2700 | |||||||||||
Attenuation P1 - P2 (dB) | 3 ± 0.8 | |||||||||||
Attenuation P1 - P3 (dB) | 3 ± 0.8 | |||||||||||
Isolation (dB) | > 20 | |||||||||||
VSWR | < 1.3 | |||||||||||
Insertion Loss (dB) | < 0.2 | |||||||||||
IM.3rd order (dBc) 2×43dBm | <-160 | |||||||||||
Impedance (Ω) | 50 | |||||||||||
Power Handing (W) | 150, Avg | |||||||||||
Mechanical Specifications | ||||||||||||
Input Connector | 2 × 4.3-10 Female | |||||||||||
Output connector | 2 × 4.3-10 Female | |||||||||||
Housing Materail | Aluminum Alloy | |||||||||||
Housing Color | Black | |||||||||||
Demensions (L×W×H)mm | 146 × 460 × 31 | |||||||||||
Weight (Kg) | 0.5 | |||||||||||
Operating Temprature (℃) | -40~+60 | |||||||||||
Application | Outdoor, IP65 |
