1 Port, V Pol 698-960/1710-2690MHz, 8dBi Directional Wall Mount indoor Antenna Low PIM

1 Port, V Pol 698-960/1710-2690MHz, 8dBi Directional Wall Mount indoor Antenna Low PIM

Model No.: YLBG-0627-P1L
Code: 22965

U.S.$ 0.00
0.00
Quantity:
Buy now
Add to cart


Model No.: YLBG-0627-P1L
Code: 22965

1 Port, V Pol 698-960/1710-2690MHz, 8dBi Directional Wall Mount indoor Antenna
Model No.: YLBG-0627-P1L Code: 22965
Electrical Specifications
Frequency Range(MHz) 698-960 1710-2700
Polarization Vertical
Half-power Horizontal Beamwidth(°) 70 60
Half-power Vertical Beamwidth(°) 55 45
Electrical down tilt(°) 0
Gain(dBi) 7 10
VSWR ≤1.5
PIM 3rd Order < -140 dBc < -140 dBc
Impedance(Ω) 50
Maximum Input Power(W) 50
Lightning protection Direct Ground
Mechanical Specifications
Connector Type N-Female
Antenna Dimentions(LxWxH) 210×180×45mm
Antenna Weight(Kg) 0.6
Weight of Fixing Kits(Kg) 0.1
Operating Temprature() -5565
Material
Radome ABS
